Gas burners

Gas

NT96WMP/WH

112 kg

600 mm

860 mm

900 mm

1 x LP Gas Converaion Kit, 2 x Oven racks, 1 x Baking tray with grill insert

Stainless steel

White

Your Plumber is able to convert this stove to LP gas using the included conversion kit.

Electric

White Cabinet, Stainless Steel cooktop, Handle & knobs.

6

Cast Iron

6

Electronic

Cast iron

2 Years

Not intended or designed for commercial use.

Oven Features
● Integrated twin cavity cooling system
● Precision thermostatic control: 0°C-250°C
● New heating fan design with better heat distribution in the oven cavity
● Turbowave Quickstart preheating function 0°C-175°C in 8 mins
● Sealed oven: lower temperatures, less food spatter
● Digital programmable timer
● A class energy rated
● Triple glazed glass door: tinted to keep the heat inside the oven and resulting in a ‘cool to touch’ door exterior
● Cool touch athermic door handles and knobs
● Select 9 multifunction cooking modes
● 97 litre oven (NET use-able space)
● Dual oven cavity lights on sides of oven for increased visibility
● Slide-out storage compartment
● Stainless steel legs can detach for a built-in ft or are adjustable from 100mm to 160mm

Cooktop Features
● 75% hand built
● AS304 stainless steel construction
● New design cast iron heavy duty trivets finished in Matt Black
● Easy in-bench serviceability
● All gas burners fitted with flame failure cut out safety devices
● Automatic electronic ignition
● Easy clean removable trivets and burners
● Deep cooktop pressing designed to retain spillages
● Solid brass burners treated with ILVE’s patented Nano technology matt black non-stick coating
● Triple ring solid brass Infinity WOK burner
● Our new burner design is up to 8% more efficient than ILVE’s previous brass burners with CO2 emission reduced by 66%
● New flame configuration with two rows of holes with a specific diameter and inclination to improve the burner and flame performance

5

Control knobs

Integrated electric grill

Incandescent

250 °C

50 °C

Upright Oven/Stove

5 Burners and Wok Burner

9

Hardwired

3.7 kW

Needs to be hardwired by a qualified electrician

15.4 A

Italy

97 L

Useable volumes quoted

Dual Fuel

Stove

97 L

Multifunction

9341584038432
