An extraction rate of 697m3/h effectively removes smoke, odours and fumes from your worktop and ensures a clean kitchen air environment. Three speed settings plus an intensive setting give you full control depending on your needs.
When turned on, LED lighting will beautifully and clearly illuminate your workspace. The metal grease filters can be simply washed with soapy water or popped into a dishwasher. For extra peace of mind, Bosch backs this rangehood with a two year warranty.
Enjoy a well-lit cooking area
To help improve the usability of your cooktop’s working space, the rangehood features LED lights for keeping your cooking area illuminated.
Easy to clean
The removable grease filters are dishwasher safe and the stainless steel hood is easy to maintain - simply wipe with a damp cloth when you have finished cooking.
Quiet, powerful extraction
This rangehood is capable of drawing out hundreds of cubic metres of air per hour, so even during cooking you can breathe easy.
Ducted ventilation
This ducted rangehood removes steam, grease, and odours from your workspace and expels them outside, leaving your kitchen environment clean and fresh. A recirculated option is also available.
Specifications & Manuals
| Rangehood Type | Canopy |
|---|---|
| Model Number | DWB97LM50A |
| Weight (kg) | 18.8 kg |
| Depth (mm) | 500 mm |
| Height (mm) | 1064 mm |
| Width (mm) | 898 mm |
| Power (W) | 145 W |
| Accessories included | 2 x Stainless Steel Flue Covers. |
| Finish Colour | Stainless Steel |
| Notes | This model can be ducted externally using the optional extra ducting kits and Recirculation Kits are available Online to add to your order.
|
| Finish Colour Description | Stainless Steel Finish. |
| Rangehood Model Number | DWB97LM50A |
| Installation Note | Wall Mounted Installation |
| Manufacturer Warranty | 2 Years |
|---|---|
| Warranty Note | 2 Year Domestic Warranty on all Parts & Labour. |
| Use | Not intended or designed for commercial use. |
| Max Air Capacity | 697 m³/h |
|---|---|
| Number of fan speeds | 4 |
| Ducting size | 150 |
| Can be recirculated | |
| Ducting location | Top |
| Features | The wall-mounted rangehood: a functional design element in the kitchen. ● Extraction rate: at 697 m3/h, it quickly ensures optimal kitchen air quality. ● Especially quiet: high performance at just 55 dB. ● LED lighting: for perfect, energy-efficient illumination of the cooktop. ● Intensive speed setting with reset: automatically resets the hood to regular speed setting after 6 min. Design & Innovation ● Box design ● Appliance colour: Stainless steel Power and Mode of Operation ● 3 power settings plus intensive setting ● Extraction rate according to EN 61591 ø 15 cm: max. Normal use 431 m3/h, Intensive 697 m3/h ● Extraction rate in recirculation mode: Max. normal use: 319 m3/h ● Ducted and recirculated-air operation ● Electronic controls with white LED display ● TouchControl ● EcoSilence BLDC brushless motor ● Noise min./max. Normal Level: 45/55 dB ● Noise max. Intensive setting: 66 dB ● Noise level in recirculation mode: Max. normal use: 70 dB(A) re 1 pW (57 dB(A) re 20 µPa sound pressure ● Energy Efficiency Class: A (at a range of energy efficiency classes from A++ to E) ● Average Energy Consumption: 33.1 kWh/year ● Power rating: 145 W Comfort & Convenience ● One-way flap: prevents outside air from entering your kitchen ● Dishwasher safe metal grease filters ● 3 x 1.5 Watt LED Lights ● Intensive operation automatic revert - 6min ● Additional sound insulation mats for optimised sound absorption Technical Information ● Appliance width: 898 mm ● Dimensions exhaust air (HxWxD): 628-954 x 898 x 500 mm ● Dimensions recirculating (HxWxD): 628-1064 x 898 x 500 mm ● Diameter pipe Ø 150 mm (Ø 120 mm enclosed) ● Electrical cable length 1.3 m |
|---|---|
| Programmable timer | |
| Control type | Touch controls |
| Light type | LED |
| Motor Type | Centrifugal |
| Boost function | |
| Clean filter indicator |
| Type of connection | 10A plug & lead |
|---|---|
| Connection requirements | This product requires a 10amp electrical connection. For more information, please contact Winning Services on 1300 020 020 or your electrician. |
| Maximum current rating | 10 A |
| Length of cord | 1.3 m |
| Filter material | Aluminum Mesh |
|---|---|
| Number of filters | 3 |
| Dishwasher safe filters |
| Noise when in operation - low to high | 45 - 66 |
|---|---|
| Noise when working | 55 dB |
| Origin | Germany |
|---|
| Primary Product Category | Rangehoods |
|---|---|
| Dishwasher safe parts | |
| Filter | Yes |
| EAN | 4242005107728 |
