Gas burners

Gas

NT96WMPMG

112 kg

600 mm

860 mm

900 mm

2 x Oven racks, 1 x Baking tray with grill insert, 1 x LP Gas Conversion Kit Included.

Graphite

Please add an extra 60mm to the overall height when using the mini Splashback.

Electric

Graphite Body with a Stainless Steel cooktop.

6

Cast Iron

Electronic

Cast iron

2 Years

Not intended or designed for commercial use.

Oven Features
● Integrated twin cavity cooling system
● Precision thermostatic control: 0°C-250°C
● New heating fan design with better heat distribution in the oven cavity
● Turbowave Quickstart preheating function 0°C-175°C in 8 mins
● Sealed oven: lower temperatures, less food spatter
● Digital programmable timer
● A class energy rated
● Triple glazed glass door: tinted to keep the heat inside the oven and resulting in a ‘cool to touch’ door exterior
● Cool touch athermic door handles and knobs
● Select 9 multifunction cooking modes
● 97 litre oven (NET use-able space)
● Dual oven cavity lights on sides of oven for increased visibility
● Slide-out storage compartment
● Stainless steel legs can detach for a built-in ft or are adjustable from 100mm to 160mm

Cooktop Features
● 75% hand built
● AS304 stainless steel construction
● New design cast iron heavy duty trivets finished in Matt Black
● Easy in-bench serviceability
● All gas burners fitted with flame failure cut out safety devices
● Automatic electronic ignition
● Easy clean removable trivets and burners
● Deep cooktop pressing designed to retain spillages
● Solid brass burners treated with ILVE’s patented Nano technology matt black non-stick coating
● Triple ring solid brass Infinity WOK burner
● Our new burner design is up to 8% more efficient than ILVE’s previous brass burners with CO2 emission reduced by 66%
● New flame configuration with two rows of holes with a specific diameter and inclination to improve the burner and flame performance

5

Control knobs

Integrated electric grill

250 °C

50 °C

Upright Oven/Stove

6 Burners

9

Hardwired

3.7 kW

Needs to be hardwired by a qualified electrician

15.4 A

Italy

97 L

Dual Fuel

Stove

97 L

9341584109569
