Specifications & Manuals
Key Specifications
| Cooktop Type | Gas burners |
|---|---|
| Cooktop Fuel Type | Gas |
| Model Number | V09CWMPMG |
| Weight (kg) | 93 kg |
| Depth (mm) | 600 mm |
| Height (mm) | 910 mm |
| Width (mm) | 900 mm |
| Accessories included | 1 x LP Gas Conversion Kit Included, 2 x Oven Wire Racks, 1 x Oven Bake/Grill Pan, 1 x Grill Insert. |
| Cooktop Material | Stainless steel |
| Finish Colour | Matte Black |
| Notes | ** If Using the mini Splashback please add 60mm to the Overall Height** |
| Oven Fuel Type | Electric |
| Finish Colour Description | Matte Black Base / Stainless Steel Cooktop. |
Burners
| Number of cooktop Burners or Zones | 5 |
|---|---|
| Burner Material | Aluminium |
| Number of cooking zones | 5 |
| Ignition | Electronic |
| Trivets | Cast iron |
| Wok burner | |
| Fish burner |
Warranty
| Manufacturer Warranty | 2 Years |
|---|---|
| Warranty Note | 2 Year Domestic Warranty on all Parts & Labour. |
| Use | Not intended or designed for commercial use. |
Other Features
| Features | ● Ilve 90cm Dual Fuel Freestanding Oven V09CWMPMG. ● Electric multifunction oven, Select 9 cooking modes. ● Delayed start and stop with the programmable timer. ● Cool Door: Removable door with dismountable inner glass for easy cleaning. ● Stainless Steel Cooktop: Stamped from a single steel sheet for an easy cleaning process and an increased safety, obtained by removing sharp edges and corners. ● Integrated twin cavity cooling system. ● Two oven cavity lights on the sides of the oven cavity. ● Cast iron heavy duty trivets and burner caps finished in Matt Black. ● Removable door with dismountable inner glass for easy cleaning. |
|---|---|
| Number of shelf positions | 5 |
| Programmable timer | |
| Control type | Control knobs |
| Grill location | Integrated electric grill |
| Light type | Halogen |
| Internal oven light | |
| Temperature Range - Maximum | 250 °C |
| Temperature Range - Minimum | 0 °C |
| Timer | |
| Fast heat-up | |
| Cooling fan | |
| Pyrolytic self cleaning | |
| Self clean catalytic oven liners | |
| Storage Drawer | |
| Oven Type | Upright Oven/Stove |
| Easy clean cooking surface | |
| Cooktop Configuration | 4 Burners and Wok Burner |
Functions
| Number of Functions | 10 |
|---|---|
| Bottom heating | |
| Full grill | |
| Light | |
| Conventional | |
| Fan forced | |
| Defrost | |
| Pizza | |
| Fan grill | |
| Intensive heat | |
| Top heating |
Electrical Connection
| Type of connection | Hardwired |
|---|---|
| Connected load | 3.7 kW |
| Connection requirements | Needs to be hardwired by a qualified electrician |
| Maximum current rating | 15.5 A |
Display
| Display |
|---|
Country of Origin
| Origin | Italy |
|---|
Volume
| Oven Volume | 96 L |
|---|---|
| Volume Note | Useable volumes quoted |
Safety Features
| Triple glazed door | |
|---|---|
| Flame failure protection | |
| Cool touch door |
(null)
| Freestanding Oven Installation Type | Dual Fuel |
|---|
Other
| Oven capacity | 96 L |
|---|---|
| Oven Timer | |
| Multi Function | |
| Steam Ovens | |
| Combination Microwave Ovens | |
| EAN | 9341584040190 |
| Dual Fuel | |
| Combination Steam Ovens |
