The 222 x 89mm Vertical Duct Elbow is designed to create a clean 90-degree change of direction in the vertical plane when installing 222 x 89mm rectangular ducting. Ideal for rangehood ventilation systems where space or building design requires a vertical duct transition, this accessory helps achieve an efficient and tidy duct layout.
Compatible with the CD13DB2 and CD13DG2 rangehood systems, this 90° vertical elbow provides a reliable connection while maintaining compatibility with your existing rectangular ducting components. It is well suited to new installations and renovation projects where ductwork needs to be routed around structural elements or through ceiling cavities.
For installations using CD13DB1 or CD13DG1 mainbox units with 222 x 89mm rectangular ducting, one OAD222X89 Mainbox Outlet Adaptor is required for each mainbox unit. This ensures the ducting system connects correctly and performs as intended.
Whether you're completing a new kitchen ventilation system or modifying an existing installation, the 222 x 89mm Vertical Duct Elbow provides a practical solution for creating smooth vertical direction changes while maintaining compatibility with supported ducting systems.
Compatible with the CD13DB2 and CD13DG2 rangehood systems, this 90° vertical elbow provides a reliable connection while maintaining compatibility with your existing rectangular ducting components. It is well suited to new installations and renovation projects where ductwork needs to be routed around structural elements or through ceiling cavities.
For installations using CD13DB1 or CD13DG1 mainbox units with 222 x 89mm rectangular ducting, one OAD222X89 Mainbox Outlet Adaptor is required for each mainbox unit. This ensures the ducting system connects correctly and performs as intended.
Whether you're completing a new kitchen ventilation system or modifying an existing installation, the 222 x 89mm Vertical Duct Elbow provides a practical solution for creating smooth vertical direction changes while maintaining compatibility with supported ducting systems.
Specifications & Manuals
Key Specifications
| Model Number | E90V222X89 |
|---|---|
| Depth (mm) | 90 mm |
| Height (mm) | 166 mm |
| Width (mm) | 473 mm |
| Finish Colour | Grey |
| Finish Colour Description | Grey Finish |
| Compatibility | CD13DB2, CD13DG2. |
| Rangehood Model Number | E90V222X89 |
| Installation Note | Downdraft Ventilation Ducting. |
Warranty
| Manufacturer Warranty | 1 Year |
|---|---|
| Use | Not intended or designed for commercial use. |
Other Features
| Features |
|
|---|
Country of Origin
| Origin | Thailand |
|---|
Other
| Primary Product Category | Rangehood Accessories |
|---|---|
| EAN | 9415112860014 |
